Cheap Price Hydraulic Universal Testing Machine WE Series

FOB Reference Price:Get Latest Price
$4,920.00 - $5,370.00 / Set | 1 Set/Sets (Min. Order)
Usage:
Compression Testing Machine Strength Testing Machine Tensile Testing Machine Bending Testing Machine Universal Testing Machine
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
XLC
Model Number:
WE-300B
Power:
Hydraulic
Product name:
Cheap Price Hydraulic Universal Testing Machine WE Series
Function:
Tensile,compression, bending, cutting , stripping and other testings
Warranty:
12 Months
Standard:
GB,ISO,ASTM,DIN
Weight:
1600kg
Color:
Requirement
Model:
WE-300B
Display:
Digital LCD Display
Accuracy:
1 Grade/0.5 Grade
Capacity:
300kN
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard export wooden box or as your request
Port
Shandong, China (Mainland)
Picture Example:
package-img

Cheap Price Hydraulic Universal Testing Machine WE Series

Product Description



Main Function and Usage

1.It is mainly used in the tensile testing of metal materials with obvious yield phenomenon.

2. Control method of rate testing: manual control.

3.It can be used in testing  the tensile strength, yield strength, percentage elongation after fracture and other mechanical performance index of the metal materials.

Main Specifications and Technical Parameter


 Model

WE-300B

 Maximum Testing Force

300kN

 Class of Testing Machine

Class 1

 Efficient Measure Range

10%-100%FS

 Relative Accuracy of Value Display

±1%

 Tensile Volume(mm)

650

 Compression Volume(mm)

600

 Column Space(mm)

430

 Round Specimen Clamping Range(mm)

Φ6-Φ26

 Flat Specimen Clamping Thickness(mm)

0-30

 Max. Width of Flat Specimen Clamping(mm)

75

 Pressure Plate Dimension(mm)

Φ160

 Overall Dimension(L*W*H)(mm)

740*590*215000

 Oil Source Console Dimension(mm)

700*700*1500

 Total Motor Power(kW)

1.5

 Total Weight(kg)

1600

--_13(1)
Testing Equipment


Packaging & Shipping

1. Packing Method: Horizontal Packing to saving moreipping cost.

 2. Packing Materials: Plywood Case metting export long transport requirement.

 3. Shiping Time: Shipped within 15-20 days after payment.

 4. Shipping Way: Shipped by sea or air is available.




Advantages


Certifications


Company Information


--_04

--_12

FAQ

 1. Why Choose Us?

>Coaxial degree of good host: Tensile test to avoid the impact of lateral force to ensure a very high test success rate
>High rigidity of the host: low failure rate, good reliability, long service life
>Measurement and control hardware: sensors, extensometers, photoelectric encoders are brand-name configuration. High accuracy, good year stability.
>Measurement and control system software: After the National Steel Materials Testing Center review. To ensure that the export data qualified, the success rate of comparative test.
>Each hydraulic universal testing machine factory has passed the 138 program test items
>Each electronic universal testing machine factory has passed 112 program test items
>Each pressure test machine factory has passed the 76 program test items
>We promise, after-sales service for 12 months, promptly and promptly deal with all the problems aftermarket.

2.Are you a factory?

>Yes,Factory+trade,17 years focusing on test instruments field.

3. What's the product delivery time?

>Within 5 days after receive the payment

4.What's your payment terms?
>We accept T/T, L/C or Western Union.

5.What's your terms of trade?
We accept EXW, FOB, CNF, CIF, and so on.
